Features:
1. easy to carry and move , can link from any direction of the car;
2. Light , dexterity , safe and firm
3. Compact structure , small volume.
Application:
Hand winch can be used in the snow , swamp , desert , beach and harsh environments , such
as muddy road on the vehicle itself , to remove obstacles , drag and drop items, installation
facilities like homework , it also can be used as a modern electronic control automatic
production line equipment , transportation , port , construction hoisting , railway construction
etc.
Model |
JC-1200 |
JC-1800 |
JC-2600 |
|
Capacity(LBS) |
1200 |
1800 |
2600 |
|
Test Load (KN) |
8 |
12 |
17.5 |
|
Gear Ratio |
4.2/1 |
5/1 |
10/1 |
|
Dimensions(mm) |
A |
182 |
244 |
292 |
|
B |
156 |
200 |
214 |
|
C |
88 |
108 |
128 |
|
D |
288 |
292 |
318 |
|
E |
51 |
56 |
60 |
|
F |
204 |
312 |
312 |
|
G |
109 |
109 |
109 |
|
H |
32 |
32 |
32 |
N.W.(kg) |
3.8 |
8.1 |
10.3 |
